KNS SERIES
Standard Process Pump, covers major Duty Points for a Chemical Process Industry applications. PFA/FEP Lining offers highest corrosion registance. Minimum lining thickness of 6 mm, lining locked by multiple locking grooves. Casing and Back Plate ingraded cast iron as per ASTM Standard, other meterials like cast steel / stainless steel available on request . Impeller PFA / FEP solid Injection Moulded.
Size: 50 mm X 32 mm
Immpeller Diameter Range: 160 - 140 mm
Best Efficiency Point: 12 m3/hr @ 25 m.
RPM: 2900
Nominal Pressure: 16 barFlange
Connection: ANSI B 16.5 class 15 RF

NS SERIES
This model is commonly used for Discharge Heads in excess of 3.5 kg/cm2, very popular for vacuum Ejector applications. PFA / FEP Lining offers highest corrosion resistance. Minimum lining thickness of 6 mm, lining locked by multiple locking grooves. Casing and back Plate in graded cast iron as per ASTM Standard, other materials like cast steel / stainless steel available on request. Impeller PFA / FEP solid Injection Moulded.

Size: 50 mm X 32 mm
Impeller Diameter Range: 200 – 170 mm
Best Efficiency Point: 30 m3/hr @ 50 m.
RPM: 2900

KNS SERIES
The largest model in KNS Lined Pumps Series, ideal for high capacity, high discharge head applications. PFA / FEP Lining offers highest corrossion resistance. Minimum lining thickness of 6 mm, lining locked by multiple locking grooves. Casing and Back Plate in graded cast iron as per ASTM Standard, other materials like cast steel / stainless steel available on request. Impeller PFA / FEP solid injection Moulded.

Size: 150 mm X 125 mm
Impeller Diameter Range: 400 – 380 mm
Best Efficiency Point: 100 m3/hr @ 30 m.
RPM: 1440
Nominal Pressure: 16 bar
Flange Connection: ANSI B 16.5 Class 150 RF
